18 TECHWELD
QUIVER / PORTABLE OVEN EQ
EQ 93S
• 9 Kg capacity
•Not Insulated
• No thermostat
EQ 97Si
• 9 Kg
capacity
• Insulated
•Thermometer
•With external
Adjustable
thermostat
Parameters
EQ93S
EQ97Si
EQ50Si
Electrode capacity
9Kg(20Lbs)
9Kg(20Lbs)
22.7Kg(50Lbs)
Max.electrode size
18”(457mm)
Working voltage
220-240V(standard, optional 48V / 70V / 110V
Wattage
200 Watts
250 Watts
350 Watts
Supply cable size
18 AWG x 3 C
18 AWG x 3 C
18 AWG x 3 C
Temp. range
Max.120°C
80-150°C
80-150°C
Thermostat
None
External
External
Thermometer
None
None
None
Heating element type U shape tabular
Mica band type
Mica band type
Insulation
None
1.5” Glass wool
1.5” Glass wool
Outer size (mm)
532x120x113
580x185x185
232x232x600
Inner chamber (mm)
450x117x110
480x111x111
153x150x470
Body
pre galvanized steel, powder coated
Handle
Fix-Handle
Fix-Handle
Fix-Handle
Tilt stand feature
Yes
No
No
Light indicator
Yes
Yes
Yes
Net weight
3.6Kg
7.15Kg
12.0Kg
EQ 50Si
• 22.7 Kg
capacity
• Insulated
•Pull-out handle
• 6” (150mm) wheel
•With external
Adjustable
thermostat
INSPECTION MIRROR
EARTH C-CLAMP
CYLINDER KEY
Four Way
M1 - 1M - M
M1 - 1M - H
500AMP
Hi Copper Series
