14 TECHWELD
WELDING CABLE
Black (HOFR-Heat, Oil and Fire Resistant)
WELDING CABLE
Double insulated Orange (TPR)
Sizes: 16mm
2
, 25mm
2
, 35mm
2
, 50mm
2
70mm
2
, 95mm
2
, 120mm
2
,
Sizes: 50mm
2
, 70mm
2
WELDING CABLE CONNECTORS
10-25 35 50 70 95 10-25 35 50 70 95
95-120
95-120
14 21 21 21 24 14
21 21 21 24
28
28
9.1 11.1 13.1 14.1 17.1 9.1
11.1 13.1 14.1 17.1
18.6
18.6
200 250 315 400 500 200 250 315 400 500
590
590
mm
X%60
mm
mm
2
• Premium Grade Orange CPE Jacket. .
• Superior Flexibility, Flame Retardant, Oil and Solvents Resistant.
• Weather and Ozone Resistant.
• Rated for -55°C to 105°C.
BLACK welding cable
• Rated for -55°C to 105°C.
• Good Flexibility. Oil Resistant.
• Resists Compression, Cuts and Abrasion.
• Black EPDM Jacket, RoHS Compliant.
APPLICATIONS
Techweld Welding Cables are resilient, resists compression cuts and abrasion, durable and survives rough handling. Designed for use as
arc welding leads from the secondary side of the power source, typical of welders and welding generators. Power supply applications not
exceeding 600 volt AC.
• Connector for connection of welding cables
• Brass body
• Insulated cover in elastomerized material, heat and
damp resistant with insulation resistance.
