Welding Catalog 2013 - page 15

13 ARCAIR
K3000 K4000
Medium Duty Heavy Duty
Accepts Accepts
Pointed Carbons Pointed Carbons
1/8” (3mm) to 3/8” (10mm) 5/32” (4mm) to 1/2” (13mm)
Flat Carbons Flat Carbons
3/8” (10mm) & 5/8” (16mm) 3/8” (10mm) & 5/8” (16mm)
Maximum 600 Amps Maximum 1000 Amps
Compressed Air Compressed Air
Pressure Pressure
80 psi (5.6kg/cm2) 80 psi (5.6kg/cm2)
Flow Rate Flow Rate
21 cfm (0.60m3/min) 28 cfm (0.79m3/min)
Torch & Cable Weight Torch & Cable Weight
4.0 lbs (1.8kg) 5.4 lbs (2.4kg)
Stock Code Description Maximum Amps
GTK3000 600A Arcair Gouging Torch 600A
GTK4000 1000A Arcair Gouging Torch 1000A
Stock code Description Size mm/inch
AGC 3/16x12” Arcair Gouging Carbons Round 4mm -5/32”
AGC 5/32x12” Arcair Gouging Carbons Round 5mm -3/16”
AGC 1/4x12” Arcair Gouging Carbons Round 6mm -1/4”
AGC 5/16x12” Arcair Gouging Carbons Round 8mm - 5/16”
AGC 3/8x12” Arcair Gouging Carbons Round 10mm - 3/8”
AGC 1/2x12” Arcair Gouging Carbons Round 13mm - 1/2”
Arcair Gouging Carbon
Designed to be used with
Arcair Gouging Torch
Features & Benefits
Natural 15˚ Torch Angle Greater operator comfort Reduced Weight Optimum cable and torch weight to minimum fatigue
360˚ Swivel Cable Less cable twist High Quality Cable Hose Best Quality cable hose offers high heat and abrasion
Less strain on operator resistance
Positive Grip Handle Greater operator feel Rugged Construction Overall rugged construction for the harsh environment
and ease in
ARCAIR GOUGING TORCH
