Page 17 - Safety Brochure - Rigman

STANDARD: EN 360
17
ART NO. CR 240
PARAMETERS
Static strength: not less than 12 kN
Braking force: less than 6 kN
Fall arresting distance: less than 2 m
• Built in brake with energy
• Dissipating mechanism inside
• Durable plastic housing
RM CR 240
RM CR 200
RETRACTABLE TYPE FALL ARRESTERS
RANGES
SIZE L MAX WEIGHT
RM CR 240 06 6m 4,10Kg LOWEST ON THE MARKET
RM CR 240 10 10m 4,30Kg
RM CR 240 15 15m 5,10Kg
Attaching swivel
4mm Galvanized steel cable
Swivel snap hook
Aluminium snap hook and
fall indicator
Holder / Anchor point
ABS Plastic case
Stainless steel ring
Zinc galvanized steel cable Ø4mm
Ref.: RM CR 200 06 - 6m cable
Ref.: RM CR 200 10 - 10m cable
Ref.: RM CR 200 15 - 15m cable
Dimensions: 208x85x280mm
Weight: RM CR 200 06 - 5,10kg
RM CR 200 10 - 5,30kg
RM CR 200 15 - 6,10kg
STANDARD: EN 360
RM CR 300
Ref.: RM CR 300 20 - 20m cable
Ref.: RM CR 300 25 - 25m cable
Ref.: RM CR 300 28 - 30m cable
Dimensions: 260x120x340mm
Weight: RM CR 300 20 - 7,50kg
RM CR 300 25- 7,90kg
RM CR 300 28 - 8,30kg
RM AZ 060
Galvanized steel
Opening : 21mm
Weight : 380g
STANDARD: EN 360
STANDARD: EN 360
19
ART NO. CR 240
PAR METERS
Static strength: not less than 12 kN
Braking force: less than 6 kN
Fall arresting distance: less than 2 m
• Built in brake with energy
• Dissipating mechanism inside
• Durable plastic housing
CR 240
RM CR 200
STEEL CABLE RETRACTOR
RETRACTABLE TYPE FA L A RESTERS
RANGES
SIZE L MAX WEIGHT
CR 240 06 6m 4,10Kg LOWEST ON THE MARKET
CR 240 10 10m 4,30Kg
CR 240 15 15m 5,10Kg
Attaching swivel
4mm Galvanized steel cable
Swivel snap hook
Aluminium snap hook and
fall indicator
Holder / Anchor point
ABS Plastic case
Stainless steel ring
Zinc galvanized steel cable Ø4mm
Ref.: RM CR 200 06 - 6m cable
Ref.: RM CR 200 10 - 10m cable
Ref.: RM CR 2 0 5 - 15m cable
Dimensions: 208x8 x280mm
Weight: RM CR 0 06 - 5,10kg
RM CR 200 10 - 5,30kg
RM CR 2 0 15 - 6,10kg
STANDARD: EN 360
RM CR 300
STEEL CABLE RETRACTOR
Ref.: RM CR 300 20 - 20m cable
Ref.: RM CR 3 0 5 - 25m cable
Ref.: RM CR 300 30 - 30m cable
Dimensions: 260x120x340mm
Weight: RM CR 300 20 - 7,50kg
RM CR 3 0 2 - 7,90kg
RM CR 300 30 - 8,30kg
RM AZ 060
Galvanized steel
Op ning : 21mm
Weight : 380g
STANDARD: EN 360
ART NO. CR 200
ART NO. CR 300
STEEL CABLE RETRACTOR
